WATERPUMP JLG 4162751

Sort waterpump:flange
Type waterpump:A1
Total height H1 (mm):138
Maximum length L1 (mm):330
Shaft diameter D1 (mm):16
Neck diameter D2 (mm):62
Flange/gear or pully diameter D3 (mm):90
Total number of mounting holes in the flange (holes + thread):4
Number of threads:4
Biggest thread TA1:M8
Metric pitch Pm1 (mm):1.25
Smallest centre distance of nearest mounting holes C1 (mm):54
Biggest centre distance of nearest mounting holes C2 (mm):54
Gasket included:YES
Weight (kg):4.54
