JLG GN96388 HYDRAULIC MOTOR
€566.00 Excl. GST
JLGGN96388 HYDRAULIC MOTOR.
Type of hydraulic motor:on the top
Length L1 (mm):279
Length L2 (mm):41
Diameter D1 (mm):127
Type of flange TY-Fl:type C
Neck diameter D2 (mm):82.5
Number of mounting holes AT-GA:4
Diameter D3 (mm):13
Centre distance C (mm):104
Type of shaft TY-AS:type E
Distance L3 (mm):116
Shaft diameter D4 (mm):32.5
Thread type TA2:1 1/8 UNEF
Pitch imperial Pi2:18
Number of connections:2
Thread type TA3:9/16 UNF
Pitch imperial Pi3:18
Description
Reliable hydraulic parts including JLG GN96388 HYDRAULIC MOTOR.
Good price, quick delivery, and secure payment. Can’t find a spare part or got a question? Get in touch with Machinery parts online customer service team.
Additional information
Weight | 17 kg |
---|---|
