Type of hydraulic motor:on the top
Length L1 (mm):269
Length L2 (mm):27
Diameter D1 (mm):126
Type of flange TY-Fl:type C
Neck diameter D2 (mm):82.5
Number of mounting holes AT-GA:4
Diameter D3 (mm):13
Centre distance C (mm):104.5
Type of shaft TY-AS:type E
Distance L3 (mm):107
Shaft diameter D4 (mm):27.5
Key width B (mm):8
Thread type TA2:1
Pitch imperial Pi2:20
Number of connections:2
Thread type TA3:9/16 UNF
Pitch imperial Pi3:18
Weight (kg):15.535
