JLG 1001113420 HYDRAULIC PUMP.

Type of pump:gearpump
Number of elements:3
Type of flange:type J
Diameter of flange mounting holes D1 (mm):9
Center distance of mounting holes flange C1 (mm):72
Center distance of mounting holes flange C2 (mm):100
Total length of pump L1 (mm):359
Neck diameter D2 (mm):80
Type of shaft:type G
Distance from flange to end L2 (mm):38
Diameter of shaft D3 (mm):13.7
Key (way) width W (mm):3
Thread type (on shaft) TA2:M12
Direction of rotation:clockwise
Position of suction port 1st element, only for pump type T POS-CO1:side
Type of connections suction port1st element, only for pump type T TY-COa:type A
Thread type of connections suction 1st element:M6
Center distance between mounting holes C-CO1a (mm):40
Position of pressure 1st element, only for pump type T POS-CO2:side
Type of connections pressure 1st element, only for pump type T TY-COb:type A
Thread type of connection pressure port 1st element TA-COb:M6
Center distance between mounting holes C-CO1b (mm):35
Position of suction port 2nd element, only for pump type T POS-CO3:side
Type of connections suction port 2nd element, only for pump type T TY-COc:type A
Position of pressure port 2nd element, only for pump type T POS-CO4:side
Type of connections pressure port 2nd element, only for pump type T TY-COd:type A
Flow control valve present:NO
Material of the housing:aluminium
