HAULOTTE 2431231030 FITS ENGINE-POWERED ARTICULATED PLATFORMS HA15DX, ELECTRIC ARTICULATED PLATFORMS HA15I / HA43E

Type of hydraulic motor:on the top
Length L1 (mm):184.5
Length L2 (mm):7
Diameter D1 (mm):86.5
Type of flange TY-Fl:type A
Neck diameter D2 (mm):82.5
Number of mounting holes AT-GA:2
Diameter D3 (mm):13.5
Centre distance C (mm):106.5
Type of shaft TY-AS:type F
Distance L3 (mm):54.5
Shaft diameter D4 (mm):25
Key width B (mm):8
Thread type TA2:M8
Pitch metric Pm2 (mm):1.25
Number of connections:2
Thread type TA3:1/2 BSP
Pitch imperial Pi3:14
