HAULOTTE 2901006080 SWITCH.

Number of connections:3
Type of the connection:blade 6,3mm
Current (A):3
Minimum voltage U1 (V):125
Maximum voltage U2 (V):250
Actuator present:YES
Type of the actuator:flat
Length of the actuator L1 (mm):22
Built-in diameter D1 (mm):12
Length thread panelmount L3 (mm):11.5
Thread size TA1:15/32
Type of thread TA1:UNS
Pitch (inch):32
Right or left handed thread:right-handed
Total length of the toggle switch L4 (mm):29
Total width of the toggle switch W2 (mm):16
Total height of the toggle switch H1 (mm):69
Sort of switch:1 pole
Type of the switch:(on)-off-(on)
Material of the housing:plastic
Material of the actuator:plastic
Cap present:NO
Symbol present:no
Light present:no
