GENIE 122495

GENIE 122495 HYDRAULIC PUMP

€790.00 Excl. GST

GENIE 122495 HYDRAULIC PUMP

Type of pump gearpump
Number of elements 2
Type of flange type A
Diameter of flange mounting holes D1 (mm) 14.3
Center distance of mounting holes C1 (mm) 146
Total length of pump L1 (mm) 234
Neck diameter D2 (mm) 101.6
Type of shaft type D
Distance from flange to end L2 (mm) 41
Diameter of shaft D3 (mm) 21.9
Number of splines 13
Direction of rotation clockwise
Position of suction port 1st element, only for pump type T POS-CO1 side
Type of connections suction port1st element, only for pump type T TY-COa type C
Thread type of connections suction 1st element 7/16 UNC
Center distance between mounting holes C-CO1a (mm) 30
Center distance between mounting holes C-CO2a (mm) 58.7
Position of pressure 1st element, only for pump type T POS-CO2 side
Type of connections pressure 1st element, only for pump type T TY-COb type E
Thread type pressure side of 1st element TA-Pb 1 1/16 UNF
Position of pressure port 2nd element, only for pump type T POS-CO4 side
Type of connections pressure port 2nd element, only for pump type T TY-COd type E
Thread type pressure side of 2nd element TA-Pd 1 1/16 UNF
Flow control valve present NO
Material of the housing metal

Out of stock

SKU: AST005375 Categories: , , Tags: ,

Description

Reliable and genuine hydraulic parts for your construction equipment. A full line of Genie Hydraulic parts: Cylinders, electrical actuators, hydraulic motors, pumps including Genie 122495, valve. We offer various models from known brands as Haulotte, JLG, Skyjack, Genie, Snorkel, and many others.

Good price, quick delivery, and secure payment. Can’t find a spare part or got a question? Get in touch with Machinery parts online Australian-based customer service team.
